| Configuration | 4 multispectral channels + 1 RGB channel |
| Sensor Size | Multispectral & RGB: 1/4" |
| Effective Pixels | Multispectral: 1.3 MP; RGB: 8.0 MP |
| Shutter Type | Multispectral: Global; RGB: Rolling |
| Quantization Depth | Multispectral: 12-bit; RGB: 8-bit |
| Field of View | Multispectral: 36.7° x 31.3°; RGB: 37.5° x 28.6° |
| Ground Resolution | Multispectral: 6.23 cm @ h120 m; RGB: 2.49 cm @ h120 m |
| Coverage Width | Multispectral: 80 m x 67 m @ h120 m; RGB: 82 m x 61 m @ h120 m |
| Spectral Channels | 555nm@27nm,660nm@22nm,720nm@10nm,840nm@30nm,RGB |
| Optical Window | Optical-grade glass window |
| Dimensions | ≤55mmx65mmx50mm |
| Weight | ≤175g |
| Mounting Interface | 7xM3 |
| Power Supply | 12V |
| Power Consumption | ≤7W@12V |
| Image Format | Multispectral: 16-bit raw TIFF & 8-bit reflectance JPEG; RGB: 8-bit JPEG (includes GPS and ambient light information) |
| Storage Medium | Standard with support for up to 64 GB capacity (U3 or above rating) micro SD card |
| Capture Trigger | Flight control trigger, external trigger, timed trigger, overlap trigger |
| Capture Frequency | 1 Hz (depends on the actual read/write speed of the storage medium) |
| Operating Ambient Temperature | -10°C to +50°C (relative wind speed ≥1 m/s) |
| Environmental Humidity | H (%) ≤85% (non-condensing) |
